Preview illustration — final product photos will replace this image.
Absorption Chiller Commercial HVAC VFD 0.75–630 kW
This general-purpose variable frequency drive (VFD) variant is configured for absorption-chiller and commercial HVAC duty, spanning 0.75–4 kW on single-phase 220 V and 0.75–630 kW on three-phase 380 V. V/f and sensorless vector control with 120% overload for 60 s match pump, fan and solution-circuit loads on chilled-water plants.
| Power range | 1-phase 220 V: 0.75–4 kW; 3-phase 380 V: 0.75–630 kW |
|---|---|
| Control mode | V/f + SVC |
| Overload capacity | 120% for 60 s |
| Motor type | Asynchronous induction |
| Options | Standard built-in I/O |
Product Description
Absorption chillers and their surrounding plant — solution pumps, refrigerant pumps, cooling-tower fans and chilled-water pumps — benefit from speed control that follows the building load curve. This VFD variant brings the standard YD platform with V/f and sensorless vector control, sized 0.75–630 kW at 380 V three-phase with 0.75–4 kW options for single-phase 220 V auxiliaries.
The 120% / 60 s overload rating suits variable-torque pump and fan duty, and built-in PID keeps chilled-water pressure or tower-fan temperature stable as the load drifts. Simple keypad setup and the shared YD parameter structure let HVAC service teams commission without specialist drive training.
Key Features
- Configured for absorption-chiller and commercial HVAC duty
- 0.75–4 kW on single-phase 220 V; 0.75–630 kW on 380 V 3-phase
- V/f and sensorless vector (SVC) control
- 120% overload for 60 seconds
- Built-in PID for stable chilled-water and tower duty
FAQ about Absorption-chiller VFD
Which chiller loads can this VFD drive?
Solution and refrigerant pumps, cooling-tower fans and chilled or condenser-water pumps on absorption-chiller plants, from small 220 V auxiliaries up to 630 kW main pumps. Tell us the motor list and we match frames within 24 hours.
Does it support constant-pressure chilled-water control?
Yes. The built-in PID accepts a pressure or temperature sensor and modulates pump speed directly, so the differential pressure tracks building demand without an external controller.
Related product range
Blower VFDOrdering Information
Standard export terms for this range. Send your motor nameplate or equipment list and we confirm the exact model, price and lead time.
- Minimum order quantity (MOQ)
- 1 set (sample orders accepted)
- Standard packaging
- Carton and plywood case packaging
- Delivery period
- 10 days after order confirmation
- Payment method
- L/C, D/A, D/P, T/T, Western Union
- Supply capacity
- 500–8,000 sets per month
- Place of origin
- Wuxi, Jiangsu, China
Plywood cases are ISPM 15 exempt — no fumigation certificate is required at destination.
