Project Cases
Delivered project records from Yolico: the plant, the machine, the variable frequency drive (VFD) that was fitted and the result that was measured on site. Grouped by industry, with photographs from commissioning.
Published: · Project location: Limestone quarry, Arequipa Region, PeruVFD for a Belt Conveyor, and the Braking Nobody Budgeted ForThree identical urgent emails, a 120 m decline, and two motors being pushed backwards by the weight of the stone. The first fix was a braking resistor. It burned through in front of us.
Published: · Project location: Foundry, Hejian, Hebei, ChinaVFD for a Dust Collector Fan, and Why the Saving Fell to 37 PercentA foundry in Hejian was losing nine workers out of twelve a year, and the owner did not care about the electricity bill. What followed was a damper test, an airflow floor nobody had measured, and a saving that fell from 66 to 37 percent.
Published: · Project location: Zhangjiagang, Suzhou, ChinaCooling Water Pump Retrofit with a Permanent-Magnet Motor in ZhangjiagangA cooling water pump driving an industrial chiller was converted to a 75 kW permanent-magnet motor on a 150 A YZJ580E drive, with local/remote control from the panel door and run and fault signals back to the plant PLC.
Published: · Project location: Linyi, Shandong, ChinaVibro-Compacting Press for Engineered Quartz Slabs: Drive Selection for a High-Inertia ShakerQuartz slab presses compact a resin-and-quartz mix with 28–51 Hz vibration under vacuum. The vibration motor has a heavy eccentric load, so drive selection follows starting inertia, not just the 110 kW nameplate.
Published: · Project location: Fuzhou, Fujian, ChinaMushroom Substrate Bagging Machine: Sizing a Drive for Hard Accel and DecelA substrate bagger weighs out each bag by counting turns of an auger. The motor reverses constantly and has to accelerate in 0.30 s and stop in 0.10 s, so the 7.5 kW motor is paired with a 25 A drive.
Published: · Project location: Shaoxing, Zhejiang, ChinaCommissioning a Linear Motor Pumping Unit: Replacing the Beam Pump's Gearbox and CrankThe beam pumping unit is famous for wasting energy in its gearbox and for regenerating on the downstroke. A 37 kW linear motor driven by a YDS8045 removes both problems — and had to be commissioned over a 1,500 m cable.
Published: · Project location: Yixing, Jiangsu, ChinaCampus Air-Conditioning Circulating Pump Drive in Yixing: Selection and CommissioningA 45 kW chilled-water circulating pump on a university campus runs on a YD580T4-37G/45P-T with terminal start, analogue frequency reference and separate run and alarm relays. Measured current: 68 A balanced.
Published: · Project location: Chemical plant, xanthan gum extractionDirect-Drive Retrofitting Xanthan Gum Fermentation Tanks: Gearbox Out, 155 rpm InA xanthan gum tank stirred at 150 rpm through a gearbox now runs a 160 rpm permanent-magnet motor direct. Production went up, and a metered comparison against a neighbouring tank showed 2,400 kWh saved per 72-hour cycle.
Published: · Project location: Wastewater treatment plants, Asia-Pacific and AfricaDecanter Centrifuge Drives on a Shared DC Bus: Recovering the Scroll's Regenerated EnergyA decanter runs a bowl motor and a scroll motor at slightly different speeds; the scroll is pushed backwards and regenerates. Wiring the two YD580 drives to one DC bus puts that energy back into the bowl instead of burning it in a resistor.
Published: · Project location: Stone quarry, wire saw cuttingCuring Overcurrent Trips on a Quarry Wire Saw: Free-Run Stop and Torque LimitsA 45 kW wire saw tripped on OC at start and mid-cut. Two settings were responsible, not the drive rating: a free-run stop that let the wire jam the kerf, and a torque limit far above what the motor could use.
