Liquid-Cooled VFD Cabinet 75–1386 A
This liquid-cooled variable frequency drive (VFD) cabinet covers 75–1386 A on three-phase 380 V with V/f and vector control and IP21 / IP54 protection. It cools by direct liquid cooling or internal-external dual-loop heat exchange, removing drive heat from the machine room without large air handlers.
Power: 75–1386 AVoltage: 380V 3PHControl: V/f + vector
| Drive capacity | Three-phase 380 V: 75–1386 A (also 75–1000 kW) |
|---|---|
| Control mode | V/f, vector |
| Protection rating | IP21 / IP54 |
| Cooling | Direct liquid; internal-external dual-loop heat exchange (external liquid source required) |
| Motor type | Asynchronous + synchronous |
| Options | AFE harmonic module; APF active filter |
Product Description
In noise-sensitive or space-constrained plants, moving drive heat by air means big ducts and big fans. This cabinet takes the heat out by liquid instead: direct liquid cooling, or an internal-external dual-loop heat-exchange design that needs an external liquid source but keeps the electronics sealed. Ratings span 75 A to 1386 A at 380 V, with a 75–1000 kW water-cooled configuration also available.
V/f and vector control drive asynchronous and synchronous motors, IP21 / IP54 options match the mounting environment, and AFE active front-end or APF active-filter modules handle harmonic requirements. The result is a drive room that is quieter, tighter and easier to cool than an air-cooled equivalent.
Key Features
- 75–1386 A on three-phase 380 V
- V/f and vector control
- Direct liquid cooling or dual-loop heat exchange
- IP21 / IP54 protection options
- Options: AFE harmonic module, APF active filter
FAQ about Liquid-cooled VFD
Why choose liquid cooling for a VFD room?
Liquid cooling removes heat at the source, so the room needs far less ventilation air. That cuts air-conditioning load, lowers noise, and lets the drives sit closer to the machines they run — useful on ships, in basements and in retrofit machine rooms.
Does the dual-loop version need a chiller?
The internal-external dual-loop design requires an external liquid source for the outer loop; the direct-liquid version connects to the plant's cooling circuit. Tell us which liquid source is available and we propose the matching configuration within 24 hours.
Related product range
Inverter Control CabinetOrdering Information
Standard export terms for this range. Send your motor nameplate or equipment list and we confirm the exact model, price and lead time.
- Minimum order quantity (MOQ)
- 1 set (sample orders accepted)
- Standard packaging
- Carton and plywood case packaging
- Delivery period
- 10 days after order confirmation
- Payment method
- L/C, D/A, D/P, T/T, Western Union
- Supply capacity
- 500–8,000 sets per month
- Place of origin
- Wuxi, Jiangsu, China
Plywood cases are ISPM 15 exempt — no fumigation certificate is required at destination.
