YD580E Synchronous Motor VFD 0.75–630 kW
The YD580E is a multi-function variable frequency drive (VFD) dedicated to permanent-magnet synchronous motors, rated 0.4–220 kW on three-phase 220 V and 0.75–630 kW on three-phase 380 V. It provides V/f, SVC and FVC control tuned for PM motor efficiency.
Power: 0.4–630 kWVoltage: 220V / 380V 3PHControl: V/f + SVC + FVC
| Power range | 0.4–220 kW (220V) / 0.75–630 kW (380V) |
|---|---|
| Input voltage | 220 V / 380 V 3-phase |
| Control mode | V/f, SVC, FVC |
| Overload capacity | Heavy 150% 60 s / Light 120% 60 s |
| Motor type | Permanent-magnet synchronous |
| Options | Comm cards, encoder cards, remote keypads |
Product Description
The YD580E applies the proven YD580 platform to permanent-magnet synchronous motors, which deliver higher efficiency and power density than induction motors. It covers 0.4–220 kW at 220 V three-phase and 0.75–630 kW at 380 V three-phase.
Dedicated PM control with rotor-position identification and auto-tuning removes the guesswork from commissioning. V/f, SVC and FVC modes, heavy-duty 150% overload and the full option set of communication, encoder and remote keypad cards make the YD580E a direct drop-in for energy-saving retrofits.
Key Features
- Dedicated permanent-magnet synchronous motor control
- Three-phase 220 V: 0.4–220 kW
- Three-phase 380 V: 0.75–630 kW
- V/f, SVC and FVC control with PM auto-tuning
- Heavy-duty 150% overload for 60 s
- Full option set: comms, encoder and remote keypad
FAQ about YD580E
Why choose a PM synchronous motor drive?
Permanent-magnet motors run at higher efficiency than induction motors, especially at partial load, so the YD580E lowers energy cost on fans, pumps and compressors. Send your motor datasheet and duty profile and we confirm the model within 24 hours.
Can the YD580E replace an induction-motor drive?
Yes, when the motor is a PM synchronous type. Identify the rotor position and run auto-tuning, then the drive follows the same V/f, SVC or FVC workflow. We provide parameter templates for common PM motors.
Which voltages are available?
The YD580E covers three-phase 220 V and three-phase 380 V. Tell us your supply and motor rating and we confirm the exact configuration.
Related product range
Low Voltage VFDOrdering Information
Standard export terms for this range. Send your motor nameplate or equipment list and we confirm the exact model, price and lead time.
- Minimum order quantity (MOQ)
- 1 set (sample orders accepted)
- Standard packaging
- Carton and plywood case packaging
- Delivery period
- 10 days after order confirmation
- Payment method
- L/C, D/A, D/P, T/T, Western Union
- Supply capacity
- 500–8,000 sets per month
- Place of origin
- Wuxi, Jiangsu, China
Plywood cases are ISPM 15 exempt — no fumigation certificate is required at destination.
